5' Bolt-on Ladder Stanchion Anchor with 12" Overhead Offset

Features

• Fully galvanized structural steel post, hardware, and fasteners for durable performance
• Included hardware and fasteners allow for quick and easy install to a wide variety of fixed ladders.
• Can be installed in the middle of ladder or off to one side for maximum access at top of ladder
• 5' and 10' post heights maintain overhead anchorage for ladders that lead up to or extend past the walking-working surface
• 12" offset optimal for harness dorsal D-ring attachment
• For permanent installation onto fixed ladders of various types and sizes.
• For use in personal fall arrest applications
• Optional rung reinforcements available for attachment to hollow rung ladders
• Meets OSHA 1926.502 and 1910.140 regulations

SKU:

6160512

UPC:

filter - osha:

OSHA Compliant

performance 2 header:

ANSI User Capacity

document name 1:

Instruction Manual

similar solutions:

6160505, 6160512W, 6160524A

material 2 header:

Anchor Bracket

performance 3 header:

OSHA User Capacity

2nd bullet:

Included hardware and fasteners allow for quick and easy install to a wide variety of fixed ladders.

family group:

Ladder Solutions

performance 1 header:

Static Strength

3rd bullet:

Can be installed in the middle of ladder or off to one side for maximum access at top of ladder

document file 2:

declarations_of_conformity/S0220034_DOC.pdf

1st bullet:

Fully galvanized structural steel post, hardware, and fasteners for durable performance

other items you may need:

727630, 7276100, 7232C, 7080B

performance 2 detail:

One user up to 310 lb max.

category tier 2:

Vertical Ladder Solutions

material 3 detail:

Galvanized and powder coated steel

performance 1 detail:

3,600 lbs min.

performance 3 detail:

Allowable up to 425 lb max.

video-link:

HyLqDlUIjLA

relevant standards 1:

OSHA 1926.502 and 1910.140

document name 2:

Declaration of Conformity

descriptor 1:

12" overhead offset for SRLs

document file 3:

sell_sheets/Ladder_Stanchions_Sell_Sheet_042020.pdf

material 2 detail:

Galvanized and powder coated steel

material 1 header:

Post

document name 3:

Sell Sheet/Brochure

material 3 header:

Mounting Hardware

material 1 detail:

Galvanized and powder coated steel

filter - ladder stanchions:

Bolt-on

product type:

5' Ladder Stanchion Anchor

descriptor 2:

Bolt-on installation

8th bullet:

Optional rung reinforcements available for attachment to hollow rung ladders

7th bullet:

For use in personal fall arrest applications

9th bullet:

Meets OSHA 1926.502 and 1910.140 regulations

4th bullet:

5' and 10' post heights maintain overhead anchorage for ladders that lead up to or extend past the walking-working surface

document file 1:

instruction_manuals/MANC29_REV_B.pdf

6th bullet:

For permanent installation onto fixed ladders of various types and sizes.

5th bullet:

12" offset optimal for harness dorsal D-ring attachment
